MALFUNCTION INSPECTION CU800 Service Manual
176
5
Front Left Upper Swing Arm
1
Front Left Upper Swing Arm:GLB Green
6
Front Right Upper Swing Arm
1
Front Right Upper Swing Arm:GLB Green
7
Front left Lower Swing Arm
1
Front left Lower Swing Arm :GLB Green
8
Front Right Lower Swing Arm
1
Front Right Lower Swing Arm:GLB Green
9
Front Shock Absorber Q
2
Front Shock Absorber Q:GLB Green
10
Swing Arm Shield II
1
11
Swing Arm Shield I
1
12
Hexagon Flange Bolt M10×1.25×55
2
13
Hexagon Flange Bolt M10×1.25×55
2
14
Hexagon Flange Locked Nut M10×1.25
14
15
Hexagon Flange Bolt M6×16
4
16
Nipple, Swim Arm
8
17
Turnup Liner For Rocker Arm Φ23×Φ28
16
18
Cylindrical Bush Φ10.3×Φ23×49.4
8
19
Hexagon Flange Bolt M10×1.25×80
8
20
Dust-Proof Bracket I
16
21
Spring Washer 12
4
22
Cotter Pin 2.5×30
4
23
Ball Joint I, Steering Knuckle
4
24
Anti-Roll Bar, Front Suspension
1
25
Rod ball kit(right)
1
26
Rod ball kit(left)
1
27
Bush Φ20×45
2
28
Mounting Cap, Cushion Rubber
2
29
Hexagon Flange Bolt M8×20
4
30
Spring Washer8
4
