5.6.1 Disassembling, Service and
Assembling the Supporting
Rocker Parts
1. Disassembling and Service
In the suspension, there is easy to appear the
problem with bushing, cotter pin and shock
absorber.
·If the left and right rocker rocks fiercely, check
the few aspect, whether the bushing of the
rocker is crushed, the middle rubber separate is
aging and chapped.
·Check whether the cotter pin is credible, if it is
not instead the same spec cotter pin.
· The problem with the shock absorber and
maintain method, whether it can return to the
position under the pressure and the torsional
spring is rupture. If it is rupture or nearly to
rupture, instead the shock absorber. If leak oil,
replace the same spec shock absorber.
According to the different request, if there is a oil
cup on the rocker, must check it whether
complete and refuels.
2. Install:
Mount fore L/R damper, up-and-down rocker
arm assembly onto the frame with Flange Bolt
M10×70 (8pcs), M10 nuts (8pcs), Flange Bolt
M10×70 (4pcs) and M10 Nut, self-locking (4pcs)
to ensure a torque of 40～45Nm.
CAUTION:
·These components should be greased with
butter before assembly.
·Do not crack the surface of components.
