MALFUNCTION INSPECTION CU800 Service Manual
181
No.
Part Name
Qty
Remarks
Removing the rear suspension
1
Rear Right Lower Swing Arm:GLB
Green
1
Rear Right Lower Swing Arm
1
2
Rear Left Lower Swing Arm:GLB Green
1
Rear Left Lower Swing Arm
1
3
Hexagon flange bolt M10×1.25×80
4
4
Turnup liner for rocker arm Φ23×Φ28
16
5
Cylindrical Bush Φ10.3×Φ23×49.4
8
6
Hexagon Flange Locked Nut M10 ×
1.25
8
7
Rear Shock Absorber
2
8
Hexagon Flange Bolt M6×16
4
9
Hexagon Flange Bolt M12×1.25×65
2
10
Hexagon Flange Bolt M12×1.25×60
2
11
Hexagon Flange Lock Nut M12×1.25
4
12
Rear Right Upper Swing Arm
1
13
Rear Right Upper Swing Arm: GLB
Green
1
Rear Left Upper Swing Arm
1
14
Rear Left Upper Swing Arm: GLB
Green
1
Hexagon Flange Bolt M10×1.25×78
4
15
Swing Arm Shield II
1
16
Swing Arm Shield I
1
17
Rear Left Upper Swing Arm
1
18
Rear Left Upper Swing Arm: GLB
Green
1
Rear Right Upper Swing Arm
1
19
Rear Right Upper Swing Arm: GLB
Green
1
Rear Left Lower Swing Arm
1
20
Rear Left Lower Swing Arm: GLB
Green
1
Rear Right Lower Swing Arm
1
Rear Right Lower Swing Arm: GLB Green
1
