ELECTRICAL SYSTEM MALFUNCTION INSPECTION CU800 Service Manual
204
1.CAN communication converter
2. 12V relay
3. Battery
4. Controller
5. DC/DC converter
6. Main contactor combination
7. Drive motor components
8. Winch assy
9. Power battery assy
10. Accelerator
11.72V reverse gear buzzer relay
12.Buzzer
7.1.1 Checking the Switch Continuity
