ELECTRICAL SYSTEM MALFUNCTION INSPECTION CU800 Service Manual
205
Refer to “CHECKING THE SWITCH” and check for continuity between lead terminals. Poor
connection, no continuity Correct or replace.
* The coupler locations are circled.
1. Light switch assy
2. Low (high) beam convert switch
3. Driven switch assy
4. The front axle differential switch
5. Emergency lamp switch
6. Left (Right) turn controller switch
7. Shift control switch
8. Mode change switch
9. Ignition switch parts
10.Winch switch
