Figure 8-3 802.1Q tag header

Table 8-5 Description on 802.1p priority

802.1p priority (decimal) 802.1p priority (binary) Description

0 000 best-effort

1 001 background

2 010 spare

3 011 excellent-effort

4 100 controlled-load

5 101 video

6 110 voice

7 111 network-management
