G Codes
96-8000 rev R June 2007
Round Island
5
8
1, 12
2
X0, Y0
4, 10
3
5
5
Tool #1 is a .500
diameter end mill
G150 Pocket Milling (Round Island)
G150 Pocket Milling (Round Island)
11
9
6, 7
Start Point
G150 Pocket milling program with a Round island.
5.0 x 5.0 x 0.500 DP. Square Pocket with Round Island
Main Program Subprogram
%%
O03010 O03020 (Subprogram for G150 in O03010)
T1 M06 (Tool is a 0.500" diameter endmill) G01 Y1. (1)
G90 G54 G00 X2. Y2. (XY Start Point) X6. (2)
S2500 M03 Y6. (3)
G43 H01 Z0.1 M08 X1. (4)
G01 Z0. F30. Y3.5 (5)
G150 P3020 X2. Y2. Z-0.5 Q0.5 R0.01 J0.3 K0.01 G41 D01 F10. X2.5 (6)
G40 G01 X2. Y2. G02 I1. (7)
G00 Z1. M09 G02 X3.5 Y4.5 R1. (8)
G53 G49 Y0. Z0. G01 Y6. (9)
M30 X1. (10)
% Y1. (11)
X2. (12) (Close Pocket Loop)
M99 (Return to Main Program)
%
