Setup Menu
UVTOCSetup and System Configuration.fm
Section 5
The communication settings are listed in Table 10:
Table 11 lists the machine status displayed in the CSV output.
5.2.7.3 Serial Output CSV
This is extended from the standard CSV format. Stream ID, TOC2, REM %
and Pass/Fail indicated by 0 or 1 as detailed below.
5.2.7.4 Addresses
This option allows the analyzer to be addressed on a multidrop system,
either X3.28 or ModBus. Each analyzer must have a different address.
If no multidrop addressing is being used, set the address to 0.
5.2.7.5 Float Format
This menu allows selection of the word order used by ModBus to represent
real numbers (floating point numbers).
Table 10 Communication Settings
Baud 9600
Parity none
Number of data bits 8
Stop bit 1
Table 11 Machine Status
ID Text ID Text
1 Online 12 Baseline Determination
2 Online 13 Baseline Determination
3 Online 14 Pre Span Period
4 Offline 15 Pre Span Period
5 Offline 16 Span Determination
6 Cleaning 17 Span Determination
7 Cleaning 18 Span Determination
8 Cleaning 19 Purging
9 Pre Zero Period 20 Purging
10 Pre Zero Period 21 Purging
11 Baseline Determination 22 Purging
Date Time Stream CO
2
ppm
Rate of
Change
TOC 1
(CH1)
REM %
(CH2)
REM % Pass/
Fail
Status Fault ID Faults EOL
MM/DD/YY 00:00:00 0 00000 ± 00000 0000.000 0.0 0.0 0 0 0 00 LFCR
Address
Float
