Measurement procedure
84 A0293_06_E00_03 HBM: public MP85A
All settings marked * (system parameters) in the PME Assistant are not over
written when parameter sets are imported (including, from firmware version
2.30, importing from the flash EPROM). The system parameters are only
restored as well during a restore process from PC -> flash. Otherwise, the last
settings made remain valid.
Internal backup:
System settings, amplifier
settings, digital IO, analysis,
data backup/statistics
Flash
MMC/SD
PC
Amplifier settings
Digital IO
Analysis (process evaluation)
Amplifier settings
Digital IO
Analysis (process evaluation)
Data backup/statistics
Fig. 8.18 Importing parameter sets from an external source (PC/MMC/SD card) or
flash
