July 2010 12 – 165
12.8 File Management of PLC Partition
Calling the
PLC partition
8 Select the Programming and Editing operating mode.
8 If open: Close the program management by pressing the END button.
8 Call the code number window.
8 Enter and confirm the code number.
8 The PLC main page is displayed.
8 Call the Program Management.
Figure: Program management of iTNC 530
The directory structure is displayed on the left, the associated files are listed on the right.
With the +/- key or with ENTER you can open and close subdirectories.
Pressing the MOD key while the program manager is open calls the interface settings.
If the dialog READONLY appears on the left side of the screen, the machine manufacturer has
protected the PLC partition with his own code number. As a result, the OEM.SYS system
file cannot be called again. All other PLC files can still be read but cannot be edited any more.
