138 smart.Turn Units
2.11 Units—Special Operations
“Defaults” form
GWW Tool change point
No axis (do not approach the tool change point)
0: Simultaneous (X and Z axes depart diagonally)
1: First X, then Z
2: First Z, then X
3: Only X
4: Only Z
5: Only Y
6: Simultaneous with Y
CLT Coolant
0: Without
1: Coolant 1 on
2: Coolant 2 on
G60 Protection zone: (default for drilling units)
0: Active
1: Inactive
“Global” form
G47 Safety clearance
SCK Safety clearance in infeed direction (drilling and milling)
SCI Safety clearance in the working plane (milling)
I, K Oversize in X, Z direction (X: diameter value)
You can load the zero point shift and the tool change point
by soft key (see soft-key table).
The setting in the “TC point” form applies only within
the current program.
Position of tool change point (WX1, WZ1, WY1):
If the tool change point is defined, you use G14 to
move to this position.
If the tool change point is not defined, you use G14 to
move to the position defined in manual mode.
