HEIDENHAIN MANUALPLUS 620 User Manual

HEIDENHAIN MANUALplus 620 225
4.9 Tool Positioning
4.9 Tool Positioning
Rapid traverse G0
G0 moves at rapid traverse along the shortest path to the target point.
Rapid traverse to machine coordinates G701
G701 moves at rapid traverse along the shortest path to the target
point.
Parameters
X Target point (diameter)
Z Target point
Programming X, Z: Absolute, incremental or modal
Parameters
X Final point (diameter)
Z Final point
X, Z refer to the machine zero point and the slide zero
point.
