6.5 Units—”Drilling, Predrilling in Y Axis” Group
6.5 Units—”Drilling, Predrilling in
Y Axis” Group
“ICP drilling, Y axis” group
“Predrilling in Y axis” group
Unit Description Page
G74_ICP_Y G74 ICP drilling, Y axis
Drilling and pecking with ICP pattern
Page 144
G73_ICP_Y G73 ICP tapping, Y axis
Tapping with ICP pattern
Page 145
G72_ICP_Y G72 ICP boring, countersinking in Y axis
Tapping with ICP pattern
Page 146
Unit Description Page
DRILL_STI_840_Y G840 ICP predrilling, contour milling in XY plane
Determine the predrilling position and machine a hole
Page 147
DRILL_STI_845_Y G845 ICP predrilling, pocket milling in XY plane
Determine the predrilling position and machine a hole
Page 149
DRILL_MAN_840_Y G840 ICP predrilling, contour milling in YZ plane
Determine the predrilling position and machine a hole
Page 150
DRILL_MAN_845_Y G845 ICP predrilling, pocket milling in YZ plane
Determine the predrilling position and machine a hole
Page 152
