436 Overview of Units
6.1 Units—“Turning” Group
6.1 Units—“Turning” Group
“Roughing” group
“Finishing” group
Unit Description Page
G810_ICP G810 Longitudinal in ICP
Roughing an ICP contour longitudinally
Page 52
G820_ICP G820 Transverse in ICP
Roughing an ICP contour transversely
Page 53
G830_ICP G830 Contour parallel in ICP
Roughing parallel to the contour in ICP
Page 54
G835_ICP G835 Bidirectional in ICP
Roughing an ICP contour in two directions
Page 55
G810_G80 G810 Longitudinal, direct
Longitudinal roughing with direct contour input
Page 56
G820_G80 G820 Transverse, direct
Transverse roughing with direct contour input
Page 57
Unit Description Page
G890_ICP G890 Contouring in ICP
Finishing an ICP contour
Page 96
G890_G80_L G890 Contouring, direct longitdnl.
Longitudinal finishing with direct contour input
Page 98
G890_G80_P G890 Contouring, direct transverse
Transverse finishing with direct contour input
Page 99
G85x_DIN_E_F_G G890 Relief, type E, F, DIN76
Finishing the undercuts according to DIN509 type E and F and the thread
undercut DIN76
Page 100
