450 Overview of G Functions
7.2 Overview of G Commands in the CONTOUR Section
G commands for C-axis contours
G commands for Y-axis contours
C-axis contour C-axis contour
Overlapping contours Overlapping contours
G308-Geo Beginning of pocket/island Page 202 G309-Geo End of pocket/island Page 202
Front and rear face contours Lateral surface contours
G100-Geo Starting point of contour, face Page 207 G110-Geo Starting point of contour, lateral
surface
Page 216
G101-Geo Line segment, face Page 208 G111-Geo Line segment, lateral surface Page 217
G102-Geo Arc cw, face Page 209 G112-Geo Arc cw, lateral surface Page 218
G103-Geo Arc ccw, face Page 209 G113-Geo Arc ccw, lateral surface Page 218
G300-Geo Bore hole, face Page 210 G310-Geo Bore hole, lateral surface Page 219
G301-Geo Linear slot, face Page 211 G311-Geo Linear slot, lateral surface Page 220
G302-Geo Circular slot cw, face Page 211 G312-Geo Circular slot cw, lateral surface Page 220
G303-Geo Circular slot ccw, face Page 211 G313-Geo Circular slot ccw, lateral surface Page 220
G304-Geo Full circle, face Page 212 G314-Geo Full circle, lateral surface Page 221
G305-Geo Rectangle, face Page 212 G315-Geo Rectangle, lateral surface Page 221
G307-Geo Polygon, face Page 213 G317-Geo Polygon, lateral surface Page 222
G401-Geo Linear pattern, face Page 214 G411-Geo Linear pattern, lateral surface Page 223
G402-Geo Circular pattern, face Page 215 G412-Geo Circular pattern, lateral surface Page 224
Y-axis contour Y-axis contour
XY plane YZ plane
G170-Geo Starting point of contour in XY
plane
Page 388 G180-Geo Starting point of contour in YZ
plane
Page 397
G171-Geo Line segment in XY plane Page 388 G181-Geo Line segment in YZ plane Page 397
G172-Geo Arc cw in XY plane Page 389 G182-Geo Arc cw in YZ plane Page 398
G173-Geo Arc ccw in XY plane Page 389 G183-Geo Arc ccw in YZ plane Page 398
G370-Geo Hole in XY plane Page 390 G380-Geo Hole in YZ plane Page 399
G371-Geo Linear slot in XY plane Page 391 G381-Geo Linear slot in YZ plane Page 399
G372-Geo Circular slot cw in XY plane Page 392 G382-Geo Circular slot cw in YZ plane Page 400
G373-Geo Circular slot ccw in XY plane Page 392 G383-Geo Circular slot ccw in YZ plane Page 400
G374-Geo Full circle in XY plane Page 392 G384-Geo Full circle in YZ plane Page 400
G375-Geo Rectangle in XY plane Page 393 G385-Geo Rectangle in YZ plane Page 401
G377-Geo Polygon in XY plane Page 393 G387-Geo Polygon in YZ plane Page 401
G471-Geo Linear pattern in XY plane Page 394 G481-Geo Linear pattern in YZ plane Page 402
G472-Geo Circular pattern in XY plane Page 395 G482-Geo Circular pattern in YZ plane Page 403
G376-Geo Single surface in XY plane Page 396 G386-Geo Single surface in XY plane Page 404
G477-Geo Centric polygon in XY plane Page 396 G487-Geo Centric polygon in XY plane Page 404
