HEIDENHAIN MANUALPLUS 620 - C-Axis Lateral Surface Drilling Group

HEIDENHAIN MANUALplus 620 439
6.2 Units—“Drilling” Group
“C-axis lateral surface drilling” group
Unit Description Page
G74_Bohr_Mant_C G74 Single hole
Drilling and pecking a single hole
Page 72
G74_Lin_Mant_C G74 Linear pattern drilling
Drilling and pecking a linear hole pattern
Page 73
G74_Cir_Mant_C G74 Circ. pattern drilling
Drilling and pecking a circular hole pattern
Page 74
G73_Gew_Mant_C G73 Tapping
Tapping a single hole
Page 75
G73_Lin_Mant_C G73 Thread, linear pattern
Tapping a linear hole pattern
Page 76
G73_Cir_Mant_C G73 Thread, circular pattern
Tapping a circular hole pattern
Page 77
