4.37 Connection between Geometry and Machining Commands
4.37 Connection between Geometry
and Machining Commands
Turning
Function Geometry Machining
Individual elements  G0 to G3
 G12/G13
 G810 Longitudinal roughing cycle
 G820 Face roughing cycle
 G830 Contour-parallel roughing cycle
 G835 Contour-parallel with neutral tool
 G860 Universal recessing cycle
 G869 Recess turning cycle
 G890 Finishing cycle
Recess  G22 (standard)  G860 Universal recessing cycle
 G870 Simple recessing cycle
 G869 Recess turning cycle
Recess  G23  G860 Universal recessing cycle
 G869 Recess turning cycle
Thread with undercut  G24  G810 Longitudinal roughing cycle
 G820 Face roughing cycle
 G830 Contour-parallel roughing cycle
 G890 Finishing cycle
 G31 Thread cycle
Undercut  G25  G810 Longitudinal roughing cycle
 G890 Finishing cycle
Thread  G34 (standard)
 G37 (general)
 G31 Thread cycle
Hole  G49 (turning center)  G71 Simple drilling cycle
 G72 Counterboring, countersinking, etc.
 G73 Tapping cycle
 G74 Deep hole drilling cycle
