4.8 Lateral Surface Contours
4.8 Lateral Surface Contours
Starting point of lateral surface contour
G110-Geo
G110 defines the starting point of a lateral-surface contour.
Parameters
Z Starting point
C Starting point (starting angle)
CY Starting point as linear value; reference: unrolled reference
diameter
Program either Z, C or Z, CY.
