438 Overview of Units
6.2 Units—“Drilling” Group
6.2 Units—“Drilling” Group
“Centric drilling" group
“ICP drilling, C axis” group
“C-axis face drilling” group
Unit Description Page
G74_Zentr G74 Centric drilling
Drilling and pecking with X=0
Page 64
G73_Zentr G73 Centric tapping
Tapping with X=0
Page 65
Unit Description Page
G74_ICP_C G74 ICP drilling, C axis
Drilling and pecking with ICP pattern
Page 78
G73_ICP_C G73 ICP tapping, C axis
Tapping with ICP pattern
Page 79
G72_ICP_C G72 ICP boring, countersinking in C axis
Tapping with ICP pattern
Page 80
Unit Description Page
G74_Bohr_Stirn_C G74 Single hole
Drilling and pecking a single hole
Page 66
G74_Lin_Stirn_C G74 Linear pattern drilling
Drilling and pecking a linear hole pattern
Page 67
G74_Cir_Stirn_C G74 Circ. pattern drilling
Drilling and pecking a circular hole pattern
Page 68
G73_Gew_Stirn_C G73 Tapping
Tapping a single hole
Page 69
G73_Lin_Stirn_C G73 Thread, linear pattern
Tapping a linear hole pattern
Page 70
G73_Cir_Stirn_C G73 Thread, circular pattern
Tapping a circular hole pattern
Page 71
