186 ISO Programming
4.4 Contour Form Elements
Example: G22-Geo
FINISHED
N1 G0 X40 Z0
N2 G1 X80
N3 G22 X60 I70 Ki-5 B-1 R0.2
Recess on face, depth is incremental
N4 G1 Z-80
N5 G22 Z-20 I70 K-28 B1 R0.2
Longitudinal recess, width is absolute
N6 G22 Z-50 Ii-8 Ki-12 B0.5 R0.3
Longitudinal recess, width is incremental
N7 G1 X40
N8 G1 Z0
N9 G22 Z-38 Ii6 K-30 B0.5 R0.2
Longitudinal recess, inside
. . .
