HEIDENHAIN MANUALplus 620 279
4.19 Thread Cycles
 Cycle stop—the MANUALplus retracts the tool from the
thread groove and then stops all tool movements. (Lift-
off distance: OEM configuration parameter:
cfgGlobalPrperties-threadliftoff)
 Feed rate override is not effective
 Create thread with G95 (feed rate per revolution)
Cycle run
1 Accelerates to feed rate (line B).
2 Moves to end point of thread—run-out length P.
3 Decelerates (line P) remains at the end point of thread.
