HEIDENHAIN MANUALplus 620 407

5.5 Tool Positioning in the Y Axis

Rapid traverse to machine coordinates G701

G701 moves the tool at rapid traverse along the shortest path to the

target point X, Y, Z and tilts the B axis.

Parameters

X Final point (diameter)

Y Final point

Z Final point

B Angle of the B axis

“X, Y, Z“ refer to the machine zero point and the slide

reference point.
