50 smart.Turn Units
2.1 smart.Turn Units
The Global form
This form contains parameters that were defined as default values in
the start unit. You can edit these parameters in the machining units.
Parameters on the Global form
G14 Tool change point
No axis
0: Simultaneous
1: First X, then Z
2: First Z, then X
3: Only X
4: Only Z
5: Only Y
6: Simultaneous with Y (X, Y and Z axes move on a
diagonal path)
CLT Coolant
0: Without
1: Coolant 1 on
2: Coolant 2 on
G47 Safety clearance: Indicates the distance to the current blank
material at which the tool is not moved at rapid traverse.
SCK Safety clearance in infeed direction: Safety clearance in
infeed direction during drilling and milling operations.
SCI Safety clearance in plane: Safety clearance in the working
plane during drilling and milling operations.
G60 Protection zone. During drilling and boring the protection
zone monitoring is
0: active
1: inactive
