155
FIGURE 7-11
The categories Level 1, Level 2, Level 3, Level
4 and Level 5, refer to the dierent
concentration levels of Liquid Controls used
in a QC test. Linearity and Proficiency define
other types of tests.
The procedure for reviewing QC Tests is the
same for all the concentration levels.
Therefore only one, Level 1, is described.
a) To view categories not initially visible,
press the Scroll bar arrow(6).
b) Select a category by pressing it.
c) All QC tests within the selected category
and the defined date interval will be
available for review. The latest test is
displayed first. For Level 1, Level 2, Level
3, Level 4 and Level 5 see FIGURE 7-12.
For Linearity see FIGURE 7-15. For
Proficiency see FIGURE 7-17.
If no data within the date interval is found,
the following message will be displayed:
No Records Found
The Previous image button(7) must be
pressed to return to the QC Test
categories image, FIGURE 7-10.
5 QC categories
6 Scroll bar arrow
7 Previous image button
LowLevel 1
NormalLevel 2
HighLevel 3
All QC DataAll QC Data
5
6
7
