156
All QC Data
All categories of QC data within the defined
date interval will be available. The dierent
images possible are described in FIGURE
7-12, FIGURE 7-15 and FIGURE 7-17.
QC tests at a specific concentration level
FIGURE 7-12
a) To browse through the available records,
use the scroll bar arrows(4).
b) Depending on the operator’s user level,
comments can either be added, deleted
or changed or just viewed, by pressing
the Comment input button(8). See 4.1.3
Entering Comments.
c) To view a graphic presentation of the
most recent QC tests at the defined
concentration level, press the Statistics
button(9).
FIGURE 7-13 will be displayed.
d) To return to the QC Test categories
image, FIGURE 7-10, press the Confirm
button(10).
1 Date and time of test
2 Operator ID
3 Lot No. of Liquid Control
4 Scroll bar arrows
5 Indicator for rejected test result
6 Result
7 Qualitative test result
8 Comment input button
9 Statistics button
10 Confirm button
QC Level 1
44 mg/dL
Pass, Warning
08/11/03
10:24 AM
OP: Kalle
Lot: 1413-1245
4
8
1
2
9
43 47 53 57
10
3
6
5
7
