71
Cuvette Batch requirement
Cuvette Batch
Not UsedNot Used
Entry RequiredEntry Required
Approved onlyApproved only
2
3
1
FIGURE 3-51
When the Cuvette Batch button is pressed in
the General Settings menu (see FIGURE
3-46), the settings for Cuvette Batch
requirements are displayed.
The options available are displayed as
buttons(1). The option currently in use is
indicated by the selected Radio button(2).
Not Used: The Cuvette Batch No. cannot be
entered.
Entry required: The Cuvette Batch No. must
be entered. The Cuvette Batch No. entered
is not verified against the predefined list.
Approved Only: The Cuvette Batch No. must
be entered and verified against the
predefined Cuvette Batch list in the Analyzer
for the result to be displayed.
a) To change the setting, press the button
for the desired option(1).
b) Press the Confirm button(3) to return to
the General Settings menu, FIGURE 3-46.
1 Options for Cuvette Batch No. requirement
2 Selected option
3 Confirm button
