90
HoursHours
DaysDays
Lockout
Interval
888
6
4
7
5
8
FIGURE 3-71
The QC lockout interval may be set in either
Hours or Days(4).
The options are displayed as buttons. The
option currently in use is indicated by the
selected Radio button(5).
The number of Hours or Days is also
displayed(6).
a) To change the setting, press the button
for the desired option(4).
b) To change the length of the time interval,
use the Scroll bar arrows(7).
c) Press the Confirm button(8).
If the reminder time needs to be
adjusted, FIGURE 3-72 will be displayed.
Otherwise FIGURE 3-73 will be displayed.
4 Time interval options
5 Selected option
6 Selected time interval
7 Scroll bar arrows
8 Confirm button
