Figure 5-3 Install Device
6. Fix the device with one screw on the mounng plate and complete the installaon.
Figure 5-4 Secure
Note
The pictures in this documentaon are for references only, refer to the actual product.
DS-K1T804B Series Fingerprint Access Control Terminal User Manual
11
