Chapter 3 Appearance Descripon
View the device appearance and the keypad's descripon.
Figure 3-1 Device Appearance
Note
The pictures here are for reference only. Some models do not support card swiping funcon. For
details, refer to the actual product.
Table 3-1 Appearance Descripon
No. Descripon
1 Keypad
2 Door Bell Buon
3 Fingerprint Reading Module
4 2.4-inch LCD Display Screen Indicator
5 USB Interface/Reset Buon (Inside the Cover)
6 Tamper-proof Buon
7 Ethernet Port
8 RS-485/Wiegand Wiring Terminal
9 12V Power Interface
10 Door Lock Wiring Terminal
11 Alarm Wiring Terminal
