HIKVISION DS-K1T804B Series User Manual

Chapter 5 Installaon
Before You Start
• Make sure that the device in the package is in good
condion and all the assembly parts are
included.
• Make sure that the wall is strong enough to withstand three
mes the weight of the device.
Steps
1. Install 120 gang box into the wall.
Figure 5-1 Install Gang Box
2. Route the cables through the cable hole of the mounng plate.
3. Secure the device mounng plate on the gang box with 2 screws (supplied).
Figure 5-2 Install Mounng Plate
4. Wire the corresponding cables.
5. Align the device with mounng plate. Push the terminal in the mounng plate from boom up.
Fasten the terminal with the buckles on the plate.
DS-K1T804B Series Fingerprint Access Control Terminal User Manual
10
