Figure 3-2 Keypad Descripon
Table 3-2 Keypad Descripon
No. Descripon
1 Exing Key: Press the buon to exit the menu.
Note
If you enable the aendance status funcon, the exing key can be the
shortcut key of the aendance status.
2 Direcon Keys: Use direcon keys to move the cursor in the menu.
Note
• If you enable the
aendance status funcon, the direcon keys can
be the shortcut key of the aendance status.
• If you are in the entering page, use the direcon key to change the
input method.
3 Numeric Keys/Leer Keys: Press to input numbers or leers.
Note
Key 0 can also represent a space key except you are using the number
input method.
4 OK Key: Press OK key to conrm operaons. Hold the key for 2 s to enter
the login interface.
