ERT-F2xxx DVR User Manual
UM ERT-F2xxx 030118NA 106
• SMTP Port No.: The SMTP port. The default TCP/IP port used for SMTP is 25.
• Enable SSL/TLS (optional): Check the checkbox to enable SSL/TLS if required by the SMTP server.
• Sender: The name of sender
• Sender’s Address: The e-mail address of sender
• Select Receivers: Select the receiver. Up to three receivers can be configured.
• Receiver: The name of user to be notified
• Receiver’s Address: The e-mail address of the user to be notified
• Test: Send a test message to verify that the SMTP server can be reached.
Click Apply to save the e-mail settings.
Click Test to test whether the e-mail settings work. The corresponding Attention message box will pop up.
Configuring NAT
Purpose:
Two ways are provided for port mapping to realize the remote access via the cross-segment network, UPnP™
and manual mapping.
• UPnP
™
Universal Plug and Play (UPnP™) can permit the device to seamlessly discover the presence of other
devices on the network and establish functional network services for data sharing, communications, etc.
You can use the UPnP™ function to enable the fast connection of the device to the WAN via a router
without port mapping.
Before You Start:
To enable the UPnP™ function of the device, you must enable the UPnP™ function of the router to which
your device is connected. When the network working mode of the device is set as multi-address, the
Default Route of the device should be in the same network segment as that of the LAN IP address of the
router.
Go to Menu > Configuration > Network.
Select NAT to enter the port mapping interface.
UPnP™ Settings Interface
