PTZ Settings
Select patrol no. in the drop-down patrol list.
Click Set to add key points for the patrol.
Key point Configuration
Configure key point parameters such as the key point no., duration to stay at one key point, and patrol
speed. The key point corresponds to the preset. Key Point No. determines the order the PTZ will follow
while cycling through the patrol. Duration refers to the time span to stay at the corresponding key point.
Speed defines the speed the PTZ will move from one key point to the next.
Click Add to add the next key point to the patrol. Click OK to save the key point to the patrol.
To delete all the key points, click Clear for the selected patrol, or click Clear All to delete all the key points
for all patrols.
Calling Patrols
Purpose:
Calling a patrol moves the PTZ according the predefined patrol path.
Click the PTZ button in the lower-right corner of the PTZ setting interface, or press the PTZ button on the
front panel, or click the PTZ Control icon in the quick setting bar, or select the PTZ option in the
right-click menu to show the PTZ control panel.
