ERT-F2xxx DVR User Manual
UM ERT-F2xxx 030118NA 30
The format of the URL is: [Type]://[IP Address of the network camera]:[Port]/[Path].
Example: rtsp://192.168.1.55:554/ch1/main/av_stream.
• Protocol Name: Edit the name for the custom protocol.
• Enable Substream: If the network camera does not support sub-stream or the sub-stream is not
needed leave the checkbox empty.
• Type: The network camera adopting custom protocol must support streaming through standard RT S P.
• Transfer Protocol: Select the transfer protocol for the custom protocol.
• Port: Set the port no. for the custom protocol.
• Path: Set the resource path for the custom protocol. E.g., ch1/main/av_stream.
The protocol type and the transfer protocols must be supported by the connected network camera.
After adding the customized protocols, the protocol name is listed in the drop-down protocol list.
Protocol Setting
Choose the protocols you just added to validate the connection of the network camera.
Enabling ONVIF
Purpose:
To interface to third-party software that conforms to the ONVIF protocol, you must enable ONVIF on the NVR.
Go to Menu > System Service > ONVIF.
Check the Enable ONVIF checkbox.
Click Apply.
Reboot the system.
