HIKVISION ERT-F204 Series User Manual

ERT-F2xxx DVR User Manual
UM ERT-F2xxx 030118NA 110
Network Traffic Interface
You can view the sending rate and receiving rate information on the interface. The traffic data is refreshed
every one second.
Configuring Network Detection
Purpose:
You can obtain the DVR’s network connecting status through the network detection function, including
network delay, packet loss, etc.
Testing Network Delay and Packet Loss
Go to Menu > Maintenance > Net Detect.
Click the Network Detection tab to enter the Network Detection menu, as shown in Figure 9-21.
Network Detection Interface
Enter the destination address in the Destination Address text field.
Click Test to start testing network delay and packet loss. The testing result pops up on the window. If the
testing fails, the error message box will pop up as well.

HIKVISION ERT-F204 Series Specifications

General

Brand	HIKVISION
Model	ERT-F204 Series
Category	DVR
Language	English
