ERT-F2xxx DVR User Manual
UM ERT-F2xxx 030118NA 93
Exceptions Setup Interface
Setting Alarm Response Actions
Purpose:
Alarm response actions will be activated when an alarm or exception occurs, including Event Hint Display, Full
Screen Monitoring, Audible Warning (buzzer), Notify Surveillance Center, Upload Picture to FTP, Trigger Alarm
Output, and Send Email.
Event Hint Display
When an event or exception occurs, a hint can be displayed on the lower-left corner of the live view image.
You can click the hint icon to check the details. The event to be displayed is configurable.
Go to Menu > Configuration > Exceptions.
Check the Enable Event Hint checkbox.
Event Hint Settings Interface
Click the icon to set the type of event to be displayed on the image.
