4.5 Head or Knee Motor
Chapter 4: Removal, Replacement, and Adjustment Procedures
Page 4 - 18 Century+™ Bed Service Manual (man241)
4.5 Head or Knee Motor
Tools required: 1/2" socket and ratchet
T25 Torx® head screwdriver
Removal
WARNING:
Powered bed mechanisms can cause serious injury. Operate the bed
only with persons clear of mechanisms.
1. Raise the bed to the high position using the hilow function.
WARNING:
Place bed stands under the upper lift arm pivots or 2 x 4s between the
frame and lift arms before working under the bed. Failure to do so could
result in personal injury.
2. Place bed stands under the upper lift arm pivots or 2 x 4s between the bed
frame and lift arms.
3. Using the knee up switch, raise the knee section to its highest point.
4. If necessary, remove the mattress from the bed.
WARNING:
When the head or foot section is folded back, tie it securely to the bed
frame before working on the bed. Failure to do so could result in
personal injury or equipment damage.
5. Lift the foot section of the sleep surface, fold it back toward the head end of
the bed, and tie it to the bed frame securely.
SHOCK HAZARD:
Unplug the bed from its power source. Failure to do so could result in
personal injury or equipment damage.
6. Unplug the bed from its power source.
