4.8 Hilow Drive Screw Assembly
Tools required: Needle nose pliers
7/16" socket and ratchet
1/2" open-end wrench
Removal
1. If necessary, remove the hilow motor from the bed (see “Hilow Motor” on
page 4-24).
SHOCK HAZARD:
Unplug the bed from its power source. Failure to do so could result in
personal injury or equipment damage.
SHOCK HAZARD:
Unplug the bed from its power source. Disconnect the battery backup.
Failure to do so could result in personal injury or equipment damage.
2. If applicable, disconnect the battery backup (see “Battery Backup Box” on
page 4-8).
3. Using the needle nose pliers, remove the two cotter pins (A) from the hilow
tie rods (B) at the head end of the bed (see figure 4-8 on page 4-28).
