7.4 Trapeze Support—P846 or P846D
Chapter 7: Accessories
Page 7 - 10 Century+™ Bed Service Manual (man241)
CAUTION:
Do not lower the bed frame while the trapeze support assembly is
attached to the bed. Use the control box lockout to deactivate the hilow
function. Equipment damage could occur.
Removal
1. Loosen and remove the bolts (C) and locknuts, and remove the trapeze
support (A) and backing plates (D) from the bed frame (B).
2. Install the hole plugs into the bed frame (B) holes.
Adjustment
None
