6.2 Extraction Tool P/N 429022 (Blue Plastic Handle)
Chapter 6: General Procedures
Page 6 - 12 Century+™ Bed Service Manual (man241)
6.2 Extraction Tool P/N 429022 (Blue Plastic Handle)
This tool is used to extract terminals from the connectors that connect to P1
and P2 on the printed circuit board.
The extraction tool tip is designed to enter the contact cavity in the front of the
connector and depress the locking lance of the contact.
The extraction tip, located at the front of the tool, fits over the pin and socket
contacts. When the tip is bottomed in the contact cavity, the contact locking
lances are forced together, allowing the contact to slide free from the housing
when the spring-loaded handle is depressed fully.
1. Holding the connector firmly with one hand, slide the extraction tool tip
over either the pin contact or socket contact.
2. Insert the tip over the contact until it bottoms in the contact cavity, causing
the locking lances of the contact to close.
3. Depress the extraction tool handle fully until the contact is pushed part way
out of the contact cavity. Remove the contact by pulling the wire attached
to the contact.
