Hill-Rom Century+ P1400 - Knee Function-Manual Operation

General Operation
Chapter 1: Introduction
Page 1 - 24 Century+™ Bed Service Manual (man241)
WARNING:
Remove the IV rod before plugging the bed into its power source.
Failure to do so could result in personal injury or equipment damage.
5. Remove the IV rod from the bed once the hilow function is at the desired
position.
Knee Function—Manual Operation
You can raise or lower the knee section using a Hill-Rom P2217 IV rod (A) as
a crank (see figure 1-12 on page 1-24). Access the knee drive (B) through the
hole in the back of the knee motor from the foot end of the bed.
Figure 1-12. Knee Function—Manual Operation
WARNING:
Unplug the bed from its power source, and disconnect the motor before
inserting the IV rod for manual operation. Failure to do so could result in
personal injury or equipment damage.
1. Unplug the bed from its power source.
m241_125
