4.7 Hilow Motor
Chapter 4: Removal, Replacement, and Adjustment Procedures
Page 4 - 24 Century+™ Bed Service Manual (man241)
4.7 Hilow Motor
Tools required: 7/16" socket and ratchet
T25 Torx® head screwdriver
Removal
WARNING:
Powered bed mechanisms can cause serious injury. Operate the bed
only with persons clear of mechanisms.
1. Using the hilow down switch, lower the bed to its lowest point.
2. Using the knee up switch, raise the knee section to its highest point.
3. If necessary, remove the mattress from the bed.
WARNING:
When the head or foot section is folded back, tie it securely to the bed
frame before working on the bed. Failure to do so could result in
personal injury or equipment damage.
4. Lift the foot section of the sleep surface, fold it back toward the head end of
the bed, and tie it to the bed frame securely.
SHOCK HAZARD:
Unplug the bed from its power source. Failure to do so could result in
personal injury or equipment damage.
5. Unplug the bed from its power source.
SHOCK HAZARD:
Disconnect the battery backup. Failure to do so could result in personal
injury or equipment damage.
6. If applicable, disconnect the battery backup (see “Battery Backup Box” on
page 4-8).
7. On one side of the bed, lower the siderails to the stored position.
8. Disconnect the hilow motor power connector (A) (see figure 4-7 on page
4-25).
