Specifications
Chapter 1: Introduction
Century+™ Bed Service Manual (man241) Page 1 - 15
1
Bed Frames
The mattress is supported by a steel frame that is 36" x 82" (91 cm x 208 cm),
and is covered with four 16 gauge formed steel panels. The panels have
molded edges for safety.
The frame has restraint attachment slots, drainage bag holders, and mattress
stops. The restraint attachment slots are part of the head and foot sections. The
rigid mattress stop is attached to the foot section, and can be folded down when
not in use.
Docking/Wall Protection
The bed can be equipped with various types of roller bumpers designed to
protect walls. The roller bumpers can be retrofitted as desired.
Siderails
The bed has two head siderails (1/2 length), and two foot siderails as standard
equipment. The siderails can be retracted and stored under the sleeping surface
frame.
Each head siderail contains head, knee, and hilow controls, and can be fitted
with a phone.
Head Siderail Configurations
The head siderails can contain a variety of bed functions and other SideCom®
Communication System controls:
• Nurse call activator (both sides required)
• Ambient light actuator (both sides required)
• Entertainment center actuator (music, TV, radio) (both sides required)
• Patient exit on/off switch, reset switch, and indicator light (one side only)
• Patient Phone (external option)
Bed Exit System
The bed exit system is an optional feature. When activated, a warning signal is
placed through the nurse call system if the patient exits the bed. There is a
selectable 2, 4, or 6 second delay in the audible signal. The selectable delay
switch and system on/off switch are located in the head siderail.
