4.9 Hilow Limit Switch
Chapter 4: Removal, Replacement, and Adjustment Procedures
Page 4 - 30 Century+™ Bed Service Manual (man241)
4.9 Hilow Limit Switch
Tools required: Phillips head screwdriver
Removal
SHOCK HAZARD:
Unplug the bed from its power source. Failure to do so could result in
personal injury or equipment damage.
1. Unplug the bed from its power source.
SHOCK HAZARD:
Disconnect the battery backup. Failure to do so could result in personal
injury or equipment damage.
2. If applicable, disconnect the battery backup (see “Battery Backup Box” on
page 4-8).
3. If necessary, remove the mattress from the bed.
WARNING:
When the head or foot section is folded back, tie it securely to the bed
frame before working on the bed. Failure to do so could result in
personal injury or equipment damage.
4. Lift the foot section of the sleep surface, fold it back toward the head end of
the bed, and tie it to the bed frame securely.
5. Using a phillips head screwdriver, loosen and remove the screw (A) and
washer (B) from the control box cover (C) (see figure 4-9 on page 4-31).
To Next Page
