Chapter 2: TroubleshootingProcedures
Page 2 - 4 Century+™ Bed Service Manual (man241)
WARNING:
Refer to your VOM owner’s manual for complete and detailed
information regarding the operation of your VOM. Failure to do so could
result in personal injury or equipment damage.
Electrical Functions
Figure 2-1 on page 2-4 represents a common digital VOM. The three basic
electrical functions that you will test are alternating current (AC), direct
current (DC), and ohms/resistance.
Figure 2-1. Volt Ohm Meter (VOM)
Figure 2-1 on page 2-4 displays the correct connection for the fine tip probes.
The red probe plugs into the port marked “V Ω.” The black probe plugs into
the port marked “COM.” The troubleshooting repair analysis procedure (RAP)
indicates where on the bed to connect the red probe and black probe.
Black probe
(COM)
Red probe
Volts AC
Volts DC
Ohms/resistance
m241_016
