4.5 Head or Knee Motor
Chapter 4: Removal, Replacement, and Adjustment Procedures
Page 4 - 20 Century+™ Bed Service Manual (man241)
9. Using the T25 Torx® head screwdriver, remove the screw (E) that secures
the ground strap.
10. Using the 1/2" socket and ratchet, remove the two bolts (D), and separate
the head motor (A) or knee motor (B) from the drive assembly.
Replacement
1. Place the head motor (A) or knee motor (B) (as applicable) on the end of
the drive assembly, ensuring that it is engaging the drive shaft.
2. Secure the head motor (A) or knee motor (B) with the two bolts (D).
3. Using the T25 Torx® head screwdriver, attach the ground strap with the
screw (E).
4. Attach the connector (C) to the motor.
5. If applicable, connect the battery backup (see “Battery Backup Box” on
page 4-8).
6. Remove the bed stands or 2 x 4s from the bed frame, as applicable.
7. Untie the foot section of the bed frame, and carefully lower it back down.
8. If applicable, install the mattress on the bed.
9. Plug the bed into an appropriate power source.
WARNING:
Powered bed mechanisms can cause serious injury. Operate the bed
only with persons clear of mechanisms.
10. Test the head motor (A) or knee motor (B) functions to ensure that the bed
is working properly.
Adjustment
None
