Getting Started
Chapter 2: Troubleshooting Procedures
Century+™ Bed Service Manual (man241) Page 2 - 3
2
Getting Started
WARNING:
Only facility-authorized maintenance personnel should troubleshoot the
Century+™ Bed. Troubleshooting by unauthorized personnel could
result in personal injury or equipment damage.
Begin each procedure in this chapter with step 1. Follow the sequence outlined
(each step assumes the previous step has been completed). In each step, the
normal operation of the product can be confirmed by answering Ye s or No to
the statement. Your response will lead to another step in the procedure, a repair
analysis procedure (RAP), or a component replacement. If more than one
component is listed, replace them in the given order.
Start with Initial Actions to begin gathering information about the problem.
Perform the Function Checks to isolate or identify a problem and to verify the
repair after completing each corrective action (replacing or adjusting a part,
seating a connector, etc.).
Perform the Final Actions after the Function Checks to verify the repair.
If troubleshooting procedures do not isolate the problem, call Hill-Rom
Technical Support at (800) 445-3720 for assistance.
These troubleshooting techniques will help you locate operational problems on
the Century+™ Bed. This section includes a list of functions and the technical
information required to inspect and diagnose problems. Wiring diagrams for
the Century+™ Bed are located in chapter 3.
Test Equipment
WARNING:
Only facility-authorized maintenance personnel should troubleshoot the
Century+™ Bed. Troubleshooting by unauthorized personnel could
result in personal injury or equipment damage.
You will need a digital or analog volt ohm meter (VOM) with fine tip probes to
troubleshoot the Century+™ Bed. The following section describes the three
basic electrical functions that you will be testing with the VOM.
