6.1 Extraction Tool P/N 91065-1
Chapter 6: General Procedures
Century+™ Bed Service Manual (man241) Page 6 - 11
6
NOTE:
The connector includes both the housing and the contacts, while the housing is
the material which encapsulates the contacts.
The lance recess is the cavity located between the contact and the connector
housing.
A solid rib (locking edge) at the rear of the lance recess cavity provides a stop
for the extraction tool. The housings are designed to prevent improper insertion
of the contacts, which are inserted into the rear of the housing.
A lug is located on the side of the Mod I housing which contains the contact
locking edge.
