Night Light Assembly—P/N 4578201
Chapter 5: Parts List
Century+™ Bed Service Manual (man241) Page 5 - 45
5
Table 5-15. Night Light Assembly—P/N 4578201
Item Number Part Number Quantity Description
1 43879 (1400) 2 Torx® button head screw
2 3438001 (1400) 1 Lamp, guarded
3 39763-02 (1400) 4 Standoff
4 45779 (1400) 1 Night light bottom cover
5 43412 (1400) 1 Night light label
6 45780 (1400) 1 Night light top cover
7 43878 (1400) 7 Torx® button head screw
8 23208 (1400) 5 Washer
9 32037 (1400) 1 Strain relief
10 16145 (1400) 1 Strain relief
11 28837 (1400) 2 Hex nut
12 29975 (1400) 2 Pin receptacle
13 3091002 (1400) 1 Plug housing
14 9000201 (1400) 0.66 lft Tubing, blank
15 3091301 (1400) 1 Plug housing socket (3 position)
16 30950 (1400) 4 Terminal (female)
17 15962 (1400) 4.83 lft 2 x 18 conductor cable
18 30966 (1400) 1 Plug housing socket
19 21492 (1400) 1 Key plug
20 3091003 (1400) 1 Connector
21 36342 (1400) 2 Pin receptacle
22 3451506 (1400) 6.66 lft Wire (2 x 40.0 dark blue)
23 34395 (1400) 5.0 lft Cable blank, 2 conductor
24 30928 (1400) 2 Splice terminal
25 14450 (1400) 1 Small cable tie
26 43977 (1400) 1 Night light sensor holder
27 30025 (1400) 1 Resistor, photo sensitive
28 9000204 (1400) 0.33 lft Tubing blank
29 46244 (1400) 1 Night light sensor bracket
