Technical Specifications
Progressa® Bed Instructions for Use (171528 REV 9) 89
TECHNICAL SPECIFICATIONS
Product Identification
Specifications for Progressa® Bed
Product Number Description
P7500 Progressa® Bed—refer to “Product Configuration
Identification” on page 102 for configurations.
Feature Dimension
Total Length—foot section extended 98" (2489 mm)*
Total Length—foot section retracted 88" (2235 mm)*
Maximum Width (siderails stored) 40.5" (1029 mm)
Maximum Width (siderails up) 40.5" (1029 mm)
Maximum Siderail Height above sleep deck 17" (432 mm)
Minimum Underbed Clearance 4.3" (109 mm) without IntelliDrive
Caster Size 6" (152 mm)
Total Weight—includes maximum SWL and
frame weight
1400 lb (635 kg)
Head Section Inclination (maximum) 67° for beds without Chair Egress
77° for beds with Chair Egress
Thigh Section Inclination (maximum) 30°
Foot Section Inclination (maximum) 45° beds without Chair Egress
75° beds with Chair Egress
Trendelenburg Position (maximum) 13°
Reverse Trendelenburg Position (maximum) 18°
Safe Working Load—includes patient weight,
mattress and accessories
650 lb (295 kg)
Patient weight 70 to 500 lb (32 to 227 kg)
Patient height 59" to 74" (150 to 188 cm)
Mattress Weight 48 lb (21.8 kg)
Progressa® Prevention Mattress Dimensions:
Mattress Width x Length x Thickness 35" x 84" x 7.125" (889 x 2133.6 x 181 mm)
Mattress Weight 31 lb (14 kg)
Headboard Weight 6.6 lb (3 kg)
Footboard Weight 14.8 lb (6.7 kg)**
Progressa® Therapy Surface Dimensions:
Mattress Width x Length x Thickness 35.5" x 84" x 8" (901.7 x 2133.6 x 203.2 mm)
Mattress Weight 45 lb (20.4 kg)
Progressa® Pulmonary Dimensions:
Mattress Width x Length x Thickness 35.5" x 84" x 8" (901.7 x 2133.6 x 203.2 mm)
Mattress Weight 48 lb (21.8 kg)
*The Transport Shelf will add 1.5” (3.8 cm) to the total length.
**The Transport Shelf will add 7 lb (3.2 kg) to the total weight.
